| . . | 100682C3 | [1] |
CHAIN (AG) |
IHCHAIN ASSEMBLY - safety, 5/16 link x 59-1/4 inch (8 x 1 504 MM) |
| 1. | 148558C1 | [1] |
CLEVIS |
IH- safety chain Superseded by part number: 1279163C1 |
| 2. | 271729 | [1] |
BOLT,Hex, 5/8" - 11 x 3 1/2", Gr 5 |
IH- hex, 5/8 NC x 3-1/2 inch Superseded by part number: 413-1056, 413-1056, NLS |
| 3. | 231-14410 | [1] |
NUT,5/8"-11, GB |
CASNUT, LOCK, 5/8"-11, GB Superseded by part number: 86639566 |
| 4. | 80280173 | [1] |
BOLT,Hex, 3/4" - 10 x 2 3/4", Gr 5 |
IMO- hex, 3/4 NC x 2-3/4 inch |
| 5. | 26512R1 | [1] |
WASHER |
IH- flat, 25/32 x 2 x 5/32 inch (20 x 51 x 4 MM) Superseded by part number: 86624159 |
| 6. | 22244R1 | [1] |
LOCK NUT |
IH- hex lock, 3/4 inch NC Superseded by part number: 86754 |
| 7. | NSS | [1] |
NOT SOLD SEPARAT |
CONPIN - clevis |
| . . | 61913C92 | [1] |
PACKAGE |
IHKIT - hardware, safety chain, Includes: Ref. 1, 2, 3, 4, 5 and 6 Superseded by part number: 495-81047, 413-1056, 413-1244, 231-14412, 231-14110, 148558C1 |
| 15. | 119354C1 | [1] |
JACK |
IHASSEMBLY - side crank (Alternate part is 135061C91), parking |
| 15. | 135061C91 | [1] |
JACK |
IHASSEMBLY - side crank (Alternate part is 119354C1), parking Superseded by part number: 119354C1 |
