| 1. | ZA105892 | [1] |
CONTROL |
CASBOX ASSEMBLY - control |
| 2. | 1261437C1 | [1] |
LAMP |
CASBULB - lamp, no. 37 |
| 3. | 131181C1 | [1] |
RELAY |
IH- control box Superseded by part number: 3221235R2 |
| 4. | ZA734450 | [1] |
HANDLE |
IH- toggle switch |
| 5. | 17175R1 | [1] |
LOCK PIN,3/16" x 1", Slotted |
IHPIN, 3/16" x 1", Slotted Superseded by part number: 118827 |
| . . | ZA103773 | [1] |
PACKAGE |
IHKIT - mounting, control box |
| 8. | NSS | [2] |
NOT SOLD SEPARAT |
CONKNOB - mounting |
| 9. | 179454C1 | [2] |
RUBBER WASHER |
IH- rubber |
| 10. | 495-21031 | [4] |
WASHER,1/4" |
CAS- flat, 5/16 x 47/64 x 3/64 inch (8 x 19 x 1 MM) Superseded by part number: 80701, 72187262 |
| 11. | ZA105277 | [1] |
BRACKET |
IH- mounting |
| 15. | 9635082 | [4] |
NUT,5/16" - 18, Gr 5 |
NH |
| 12. | 1261522C91 | [1] |
BRACKET, SUPPORTING |
IHBRACKET ASSEMBLY - cab mounting |
| 13. | 598802R1 | [4] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 3/4", G5, Full Thd |
IHBOLT - round head square neck, 5/16 NC x 3/4 inch Superseded by part number: 280497 |
| 14. | 116120 | [4] |
LOCK WASHER,5/16" |
IHWASHER, LOCK, 5/16" Superseded by part number: 83990583, 322358 |
| 17. | ZA104615 | [1] |
HARNESS |
IH- tractor |
| 18. | ZA104616 | [1] |
HARNESS |
IH- control box |
| 19. | ZA105525 | [1] |
HARNESS |
CAS- baler |
| 20. | ZA103745 | [1] |
HARNESS |
IH- extension |
| 21. | ZA105270 | [1] |
HARNESS |
IHKIT - harness, emergency (For temporary operation of actuator) (Also order switch 91774C1) |
| 22. | 91774C1 | [1] |
ASSEMBLY |
IHSWITCH - toggle, double pole double throw, momentary |
| 23. | REF | [1] |
INSTRUCTION |
NHACTUATOR - twine tube (See page 4) |
| 24. | ZA103633 | [1] |
SWITCH |
IH- bale density Superseded by part number: 232773A1 |
| 25. | ZA104562 | [1] |
COVER |
IHASSEMBLY - switch Superseded by part number: 230414A1 |
| 26. | 120221 | [4] |
NUT,Sl Rnd Hd, #10 - 24 x 1/2" |
IHSCREW - round head slotted, no. 10 NC x 1/2 inch Superseded by part number: 159920 |
| 27. | 221431 | [2] |
WASHER - flat, 5/32 x 1/32 inch (4 x 10 x 1 MM) | |
| 28. | 120217 | [4] |
LOCK WASHER,#10 |
IHWASHER, LOCK, #10 Superseded by part number: 80684 |
| 29. | 26303R1 | [4] |
HARDWARE,#10-24 |
IHNUT - hex, no.10 NC Superseded by part number: 3062835R1 |
| 30. | ZA104394 | [1] |
BUSHING |
IH- strain relief |
| 31. | 169851C1 | [1] |
GROMMET |
IHBUSHING - strain relief |
| 32. | 299407C1 | [4] |
CLAMP |
IH- tube Superseded by part number: 86010402 |
| 33. | 299404C1 | [8] |
CLAMP |
IH- tube Superseded by part number: 86572009 |
| 34. | 533959R1 | [1] |
CABLE TIE,.135" x 11" |
IHSTRAP - tie Superseded by part number: 529070 |
| . . | ZA105438 | [1] |
KIT |
CAS- connector |
| 35. | 245430C1 | [1] |
CONNECTOR, ELEC |
IHCONNECTOR - male, 8 terminal Superseded by part number: 87698229 |
| 36. | 3195530R1 | [1] |
CONNECTOR, ELEC |
CASCONNECTOR - female, 8 terminal |
| 37. | 877291R1 | [1] |
ELEC CONNECTOR,Female |
IHCONNECTOR - male, 2 terminal Superseded by part number: 87693325 |
| 38. | 872290R1 | [1] |
ELEC CONNECTOR,Male |
IHCONNECTOR - fe, 2 terminal Male Superseded by part number: 87697530 |
| . . | 739145C1 | [10] |
ELEC. TERMINAL PIN,Male, 3 - 5 mm2 |
IHTERMINAL - male (Not shown) Superseded by part number: 87697669 |
| . . | 739067C1 | [10] |
TERMINAL CONNECTOR,Female, 5 mm2 |
CASTERMINAL - female (Not shown) Superseded by part number: 87703293 |
| 39. | ZA104561 | [1] |
BRACKET |
IH- switch |
| 40. | 120391 | [2] |
WASHER,#10 |
IH- flat, 7/32 x 1/2 x 1/32 inch (6 x 13 x 1 MM) Superseded by part number: 9824326 |
| 41. | 488837C1 | [1] |
SPRING NUT |
IH- speed, U type, 5/16 inch |
