| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 001. | 1532174283 | [1] | PULLEY FAN DRIVE | 0.0000(lbs); 0.000 |
| 002. | 0571200720 | [1] | KEY FEATHER | 0.0176(lbs); 0.008 |
| 003. | 1522123360 | [1] | NUT CRANKSHAFT | 0.2420(lbs); 0.110 |
| 004. | 1522123380 | [1] | WASHER CRANKSHAFT | 0.0440(lbs); 0.020 |
| 005. | 1532172060 | [1] | ASSY RADIATOR | 0.0000(lbs); 0.000 |
| 007. | 1502172632 | [1] | CAP RADIATOR | 0.0000(lbs); 0.000 |
| 008. | 1532172710 | [1] | PIPE WATER OVER FLOW | 0.0000(lbs); 0.000 |
| 009. | 1532172250 | [1] | NET RADIATOR | 3.5200(lbs); 1.600 |
| 010. | 0105350612 | [4] | BOLT | 0.0088(lbs); 0.004 |
| 011. | 0451200060 | [4] | WASHER LOCK | 0.0000(lbs); 0.000 |
| 012. | 0401350060 | [3] | WASHER FLAT | 0.0022(lbs); 0.001 |
| 013. | 1430173114 | [1] | ASSY COCK DRAIN | 0.0000(lbs); 0.000 |
| 014. | 1502172042 | [1] | WHISTLE | 0.0000(lbs); 0.000 |
| 015. | 1532172530 | [1] | BELT FAN | ; <=1003 0.0198(lbs); 0.009 |
| 015. | 1532172532 | [1] | BELT FAN | ; =>1004 0.0000(lbs); 0.000 |
| 016. | 1532172850 | [1] | PIPE WATER 1 | 0.3520(lbs); 0.160 |
| 017. | 1510872873 | [2] | BAND | 0.0000(lbs); 0.000 |
| 018. | 1522164010 | [1] | ASSY ALTERNATOR | ; <=1003 5.9400(lbs); 2.700 |
| 018. | 1532164010 | [1] | ASSY ALTERNATOR | ; =>1004 0.0000(lbs); 0.000 |
| 018. | 1532164012 | [1] | ASSY ALTERNATOR | ; =>5870 0.0000(lbs); 0.000 |
| 020. | 1522191010 | [1] | BOLT | 0.0000(lbs); 0.000 |
| 021. | 0105350835 | [1] | BOLT | 0.0352(lbs); 0.016 |
| 022. | 0451200080 | [2] | WASHER LOCK | 0.0000(lbs); 0.000 |
| 023. | 0401250080 | [2] | WASHER FLAT | 0.0022(lbs); 0.001 |
| 024. | 1532164350 | [1] | SUPPORT ALTERNATOR | 0.6380(lbs); 0.290 |
| 025. | 0105350825 | [2] | BOLT | 0.0308(lbs); 0.014 |
| 026. | 0451200080 | [2] | WASHER LOCK | 0.0000(lbs); 0.000 |
| 027. | 1532164420 | [1] | STAY ALTERNATOR | 0.2200(lbs); 0.100 |
| 028. | 1510194612 | [1] | LABEL RADIATOR | 0.0000(lbs); 0.000 |
| 029. | 1532111703 | [1] | ASSY HOLDER INLET PI | 0.0000(lbs); 0.000 |
| 030. | 0451200080 | [1] | WASHER LOCK | 0.0000(lbs); 0.000 |
| 031. | 0205600080 | [1] | NUT | 0.0000(lbs); 0.000 |
| 032. | 3415034482 | [1] | CLAMP ALTERNATOR COD | ; <=1003 0.0000(lbs); 0.000 |
| 032. | 1532167572 | [1] | CLAMP CODE | ; =>1004 0.0000(lbs); 0.000 |
| 033. | 0451210050 | [1] | WASHER LOCK | 0.0000(lbs); 0.000 |
| 034. | 0205650050 | [1] | NUT | 0.0044(lbs); 0.002 |
| 035. | 1510194880 | [1] | CARD | 0.0000(lbs); 0.000 |
| 036. | 3420013850 | [1] | COVER FAN | L225DT; =>10001 0.0000(lbs); 0.000 |
| 037. | 0122250612 | [2] | BOLT | L225DT; =>10001 0.0088(lbs); 0.004 |
| 038. | 0401250060 | [2] | WASHER FLAT | L225DT; =>10001 0.0022(lbs); 0.001 |
| 039. | 0451250060 | [2] | WASHER LOCK | L225DT; =>10001 0.0022(lbs); 0.001 |
| 040. | 1532164690 | [1] | COVER ALTERNATOR | D1100-A; <=4869 0.3520(lbs); 0.160 |
| 040. | 3426013863 | [1] | COVER BELT LH | L225DT; =>10001 0.0000(lbs); 0.000 |
| 041. | 3420013872 | [1] | COVER BELT LOWER | L225DT; =>10001 0.0000(lbs); 0.000 |
