| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 001. | 3765043110 | [1] | CASE DIFF GEAR | 13.2000(lbs); 6.000 |
| 002. | 0633135012 | [1] | PLUG | 0.0528(lbs); 0.024 |
| 003. | 0471701200 | [1] | WASHER SEAL | 0.0044(lbs); 0.002 |
| 004. | 3765043120 | [1] | CASE DIFF BEARING | ; <=10865 5.8740(lbs); 2.670 |
| 005. | 3765043160 | [4] | SHIM | 0.0044(lbs); 0.002 |
| 005. | 3765043130 | [4] | SHIM | 0.0110(lbs); 0.005 |
| 006. | 3765043170 | [2] | SHIM | 0.0088(lbs); 0.004 |
| 006. | 3765043140 | [2] | SHIM | 0.0110(lbs); 0.005 |
| 007. | 0117351028 | [8] | BOLT | ; <=10865 0.0484(lbs); 0.022 |
| 008. | 0451250100 | [8] | WASHER SPRING | ; <=10865 0.0066(lbs); 0.003 |
| 009. | 3715026480 | [2] | WASHER SPRING | ; =>50001 0.0352(lbs); 0.016 |
| 010. | 9999999999 | [1] | BLANK | ORDER BY REF.No.036; =>52472 0.0000(lbs); 0.000 |
| 011. | 3765043220 | [1] | COLLAR OIL SEAL | 0.1100(lbs); 0.050 |
| 012. | 3765043230 | [1] | CASE PINION BEARING | 1.9140(lbs); 0.870 |
| 013. | 3122022340 | [1] | NUT | 0.0726(lbs); 0.033 |
| 014. | 3765043280 | [4] | SHIM | 0.0022(lbs); 0.001 |
| 014. | 3765043270 | [6] | SHIM | 0.0066(lbs); 0.003 |
| 015. | 0481100240 | [1] | O RING | 0.0022(lbs); 0.001 |
| 016. | 0481150700 | [1] | O RING | 0.0044(lbs); 0.002 |
| 017. | 0871130305 | [1] | BEARING TAPER ROLLER | 0.5852(lbs); 0.266 |
| 018. | 0871130205 | [1] | BEARING TAPER ROLLER | 0.3256(lbs); 0.148 |
| 019. | 0950035528 | [1] | SEAL OIL | 0.0374(lbs); 0.017 |
| 020. | 0115650822 | [4] | BOLT | 0.0220(lbs); 0.010 |
| 021. | 0451250080 | [4] | WASHER SPRING | 0.0044(lbs); 0.002 |
| 022. | 3765043310 | [1] | CASE DIFFERENTIAL | ; <=10005 0.0000(lbs); 0.000 |
| 022. | 3780043310 | [1] | CASE DIFFERENTIAL | ; =>50001 4.6420(lbs); 2.110 |
| 023. | 3765043320 | [1] | PIN SNAP | 0.0220(lbs); 0.010 |
| 024. | 3765043330 | [1] | SHAFT DIFF PINION | 0.6600(lbs); 0.300 |
| 026. | 3122026360 | [2] | BUSH | 0.0330(lbs); 0.015 |
| 027. | 3122026390 | [2] | WASHER DIFF PINION | 0.0000(lbs); 0.000 |
| 028. | 3415026430 | [2] | GEAR DIFF SIDE RH | 0.0000(lbs); 0.000 |
| 028. | 3844044980 | [1] | GEAR DIFF SIDE RH | 0.0000(lbs); 0.000 |
| 029. | 3122026480 | [2] | WASHER | 0.0330(lbs); 0.015 |
| 029. | 3122026490 | [2] | WASHER | 0.0440(lbs); 0.020 |
| 031. | 3765043360 | [1] | BUSH | 0.0858(lbs); 0.039 |
| 032. | 0810106011 | [1] | BEARING BALL(6011) | 0.8272(lbs); 0.376 |
| 033. | 0810106010 | [1] | BEARING BALL(6010) | 0.5764(lbs); 0.262 |
| 034. | 3765043370 | [3] | STOPPER | ; <=10865 0.0330(lbs); 0.015 |
| 035. | 3435026250 | [6] | BOLT | ; <=10865 0.0000(lbs); 0.000 |
| 035. | 3780043870 | [6] | BOLT | ; =>50001 0.0572(lbs); 0.026 |
| 036. | 3780043200 | [1] | ASSY SPIRAL BEVEL | 7.1940(lbs); 3.270 |
| 037. | 3122026300 | [1] | ASSY PINION DIFFEREN | 0.3410(lbs); 0.155 |
| 038. | 3415026440 | [1] | GEAR DIFF SIDE LH | 0.0000(lbs); 0.000 |
| 038. | 3818026440 | [1] | GEAR DIFF SIDE LH | 1.3420(lbs); 0.610 |
