| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 001. | 3415028100 | [1] | ASSY BRAKE R | 0.0000(lbs); 0.000 |
| 002. | 3415028300 | [1] | ASSY BRAKE L | 8.8000(lbs); 4.000 |
| 003. | 3415028150 | [2] | PLATE ANCHOR | 3.3880(lbs); 1.540 |
| 004. | 0117351022 | [12] | BOLT | 0.0418(lbs); 0.019 |
| 005. | 0451250100 | [12] | WASHER LOCK | 0.0066(lbs); 0.003 |
| 006. | 0501201016 | [4] | PIN STRAIGHT | 0.0220(lbs); 0.010 |
| 007. | 3415028210 | [2] | COVER BRAKE | 1.4080(lbs); 0.640 |
| 008. | 3415028220 | [2] | GASKET | 0.0352(lbs); 0.016 |
| 009. | 0120250612 | [16] | BOLT | 0.0110(lbs); 0.005 |
| 010. | 3415028269 | [1] | LEVER BRAKE CAM L | 0.0000(lbs); 0.000 |
| 011. | 3415028278 | [1] | LEVER BRAKE CAM R | 0.0000(lbs); 0.000 |
| 012. | 0461210220 | [2] | CIR-CLIP EXTERNAL | 0.0000(lbs); 0.000 |
| 013. | 0481100180 | [2] | O RING | 0.0022(lbs); 0.001 |
| 014. | 3415028119 | [2] | DRUM BRAKE | ; <=15033 0.0000(lbs); 0.000 |
| 014. | 3415028142 | [2] | DRUM BRAKE | ; =>15034 0.0000(lbs); 0.000 |
| 015. | 0461210280 | [4] | CIR-CLIP EXTERNAL | 0.0000(lbs); 0.000 |
| 016. | 3415928200 | [4] | ASSY SHOE BRAKE | ; <=12403 0.0000(lbs); 0.000 |
| 016. | 3415028202 | [4] | ASSY SHOE BRAKE | ; =>12404 0.0000(lbs); 0.000 |
| 017. | 3122028134 | [4] | SPRING | 0.0000(lbs); 0.000 |
| 018. | 3415028412 | [1] | SHAFT BRAKE PEDAL | 0.0000(lbs); 0.000 |
| 019. | 3215028460 | [1] | COLLAR | 0.0154(lbs); 0.007 |
| 020. | 0461210250 | [1] | CIR-CLIP EXTERNAL | 0.0000(lbs); 0.000 |
| 021. | 3415928400 | [1] | SUPPORT PEDAL SHAFT | 2.1120(lbs); 0.960 |
| 022. | 3212014752 | [2] | BUSHING | ; <=12303 0.0000(lbs); 0.000 |
| 022. | 3415028430 | [2] | BUSHING | ; =>12304 0.0880(lbs); 0.040 |
| 023. | 0117351022 | [4] | BOLT | 0.0418(lbs); 0.019 |
| 024. | 0451250100 | [4] | WASHER LOCK | 0.0066(lbs); 0.003 |
| 025. | 3415028170 | [2] | GASKET | ; =>10304 0.0066(lbs); 0.003 |
| 026. | 0661310675 | [1] | NIPPLE GREASE | 0.0066(lbs); 0.003 |
| 027. | 3415028610 | [1] | PEDAL BRAKE L | ; <=10303 2.7280(lbs); 1.240 |
| 027. | 3415028613 | [1] | PEDAL BRAKE L | ; =>10304 0.0000(lbs); 0.000 |
| 028. | 0541110840 | [1] | PIN SPRING | 0.0000(lbs); 0.000 |
| 029. | 3415928600 | [1] | ASSY PEDAL BRAKE | 2.9480(lbs); 1.340 |
| 030. | 3212014753 | [2] | BUSHING | 0.0000(lbs); 0.000 |
| 031. | 0661310675 | [1] | NIPPLE GREASE | 0.0066(lbs); 0.003 |
| 032. | 3415928930 | [2] | ROD BRAKE 1 | 0.2552(lbs); 0.116 |
| 033. | 3415028942 | [2] | ROD BRAKE 2 | 0.0000(lbs); 0.000 |
| 034. | 6373342412 | [2] | BUCKLE TURN | ; <=11343 0.0000(lbs); 0.000 |
| 034. | 6659142413 | [2] | BUCKLE TURN | ; =>11344 0.0000(lbs); 0.000 |
| 035. | 0211250080 | [2] | NUT | 0.0066(lbs); 0.003 |
| 036. | 0401250080 | [4] | WASHER FLAT | 0.0022(lbs); 0.001 |
| 037. | 0551150315 | [4] | PIN SPLIT | 0.0044(lbs); 0.002 |
| 038. | 3415015842 | [2] | SPRING | ; <=10628 0.0000(lbs); 0.000 |
| 038. | 3415028950 | [2] | SPRING | ; =>10629 0.1276(lbs); 0.058 |
